Water supply in residential, civil and industrial applications
Reliable single-impeller centrifugal pump characterized by low noise level and high flow rate. It is used for the pressurization of small irrigation systems and water supply in general. Three-phase power supply.
It is advisable to protect the pump from malfunctions of the power line.
Available in a V230M single-phase version.
|
|||
|
Power |
Volts |
Flow Rate |
VAT |
|
|||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
kW |
Hp |
Q=l/min' |
0 |
160 |
200 |
300 |
400 |
480 |
520 |
|||||
Q=m3/h |
0 |
9,6 |
12 |
18 |
24 |
28,8 |
31 |
|||||||
CEA 370/1 TRIFASE |
1,10 |
1,50 |
3x400 |
H=ml |
16,3 |
15,5 |
15,2 |
13 |
9,4 |
- |
- |
Sconto 48 % |
|
|
CEA 370/2 TRIFASE |
1,50 |
2,00 |
3x400 |
H=ml |
20,4 |
19,6 |
19,1 |
17,2 |
14,1 |
10,8 |
- |
Sconto 48 % |
|
|
CEA 370/3 TRIFASE |
1,85 |
2,50 |
3x400 |
H=ml |
24,4 |
23,5 |
22,9 |
21,1 |
18,2 |
15 |
13 |
Sconto 48 % |
|
|
CEA 370/5 TRIFASE |
3,00 |
4,00 |
3x400 |
H=ml |
30,4 |
29 |
28,3 |
26,5 |
23,8 |
20,8 |
19 |
Sconto 48 % |
|
