Product: SPEEDRIVE ESPA variable frequency inverter system - Variable-frequency drive (VFD) for pumps
click to zoom the image
|
Constant pressure system
Constant pressure inverter system for pumps with three-phase motors.
Nomenclature: Speedrive
Company: Espa
Function: constant pressure management Available versions:single-phase/three-phase & three-phase/three-phase Technology: Adjustable-frequency drive Heat dissipation: forced air by the motor Adjustment range: from 0.3Bar to 10Bar Max power: 3Kw - 9A (SPEEDRIVE T3) Installation: on the motor terminal board - or on the wall (request kit) Transducer: 10Bar (not included)
Expansion vessel/tank: recommended (min.20% max flow of the pump)
Why should you add the expansion vassel to the frequency inverter drive system?
The basic plant does not require the use of a compensation tank/vassel. But if you want to maximize the energy consumption and the duration of the electric pump, it's necessary to add a tank. In fact, by using a water tank, the continuous and repeated starts of the electric pump (due to small withdrawals and/or water leaks in the water system) are avoided; Decreasing the start/stop of the electric pump:
1) Decreases energy consumption;
|
|||
|
|
Inverter Power Supply |
Pump Power Supply |
Max power load (KW) |
Max power load (A) |
|
VAT EXCLUSIVE
|
|
|---|---|---|---|---|---|---|---|
|
SPEEDRIVE.M2 (MT) |
V230 Monofase | V230 Trifase | 1,50 kW | 7,00 A |
Sconto 40 % |
|
|
|
SPEEDRIVE.T2 (TT) |
V400 Trifase | V400 Trifase | 3,00 kW | 6,00 A |
Sconto 40 % |
|
|
|
SPEEDRIVE.T3 (TT) |
V400 Trifase | V400 Trifase | 4,00 kW | 9,00 A |
Sconto 40 % |
|
|
|
SPEEDRIVE.TR. (PER MOD. TRIFASE) MODULO A PARETE |
V400 Trifase | V400 Trifase | ---- | ---- |
Sconto 40 % |
|
|
|
TRASDUTTORE SPEEDRIVE 10 BAR |
---- | ---- | ---- | ---- |
Sconto 40 % |
|
.png)
Attention: the power value (maximum power load) is indicative. For a correct match with the electric pump, it is essential to verify that the amps absorbed by the electric pump do not exceed the amps allowed by the inverter.
ESPA SPEEDRIVE VARIABLE FREQUENCY DRIVE
VFD inverter system are designed to operate pumps with three-phase motors at constant pressure.
The series includes the M2 230Vac single-phase input voltage and the T2 and T3 models of three-phase/three-phase type;
Espa Speedrive must be coupled & connected directly to the motor control board. Motor air induced cooling.
10 BAR transducer
The newly developed Speedrive Espa inverters are able to work in groups of up to 4 pumps with VFD in communication;
They provide pumping systems with better hydraulic features, constant stable pressure, smooth and silent operation, extended lifespan of pumps, savings in electricity consumption resulting in cost reductions over the life cycle of the installation.
3x400 Three-phase surface pumps with TT VFD (connectable in 3x230 three-phase with MT single-phase/three-phase VFD)
3x400 Sub pump (TT VFD), 3x230 thre-phase (MT sigle-phase/three-phase VFD)
Complete your system with the help of Pippohydro
Pressure Tanks:
Elbi expansion tanks D series
Elbi expansion tanks DV series
Expansion vessels up to 36 liters
Base expansion tanks from 36 to 150 liters liters
Global C2 LITE floor standing expansion tanks
Choose the frequency inverter: an efficient way for energy saving
