Lifting system for well with submersible pump
including filtration and pressure boosting unit with surface pump


1. SUBMERSIBLE PUMP
2. HYDROCYCLONE
3. WATER TANK
4. ELECTRIC FLOAT SWITCH FOR TANK FILLING
5. DRYCONTROL  PANEL
6. PUMP ST AND VFD
7. FILTER
8. PRESSURE VASSEL
9. USES


The use of the hydrocyclone before the tank, and that of a 50 micron filter after the tank, allows the system to be cleaned from sand and silt.

schema gruppo pompa sommersa ed elettropompa per irrigazione
